兽用生物刺激激光器 / 马科动物 GBOX PLUS

马运输式用于康复治疗

What is Laser Therapy?
Non-invasive Class 4 Laser Therapy penetrates deep into tissues, accelerating healing, reducing inflammation, and helping horses recover faster.

Ideal for:

• Post-race recovery
• Tendon injuries
• Arthritis
• Pain management
• Preventive care

The Ultimate Equine Recovery Solution
Multi-wavelength therapy combining 1064nm, 980nm, 915nm, 810nm and 635nm for layered tissue effects; available in CW and Intense Superpulse (ISP) modes. CW40W + 2W (635nm) and ISP55W + 2W (635nm) options provide both continuous and pulsed high-peak treatments.

Powerful and portable GBOX PLUS

• High-power Class 4 laser technology
• Multi-wavelength for deep tissue penetration (combinations selectable and independently controllable)
• Smart handpiece for easy operation (5 handpiece optics)
• Ideal for racehorse facilities, veterinary clinics and equine care centers

Highlighted Features

• Create Custom Protocols: design and save personalized treatment protocols per patient
• 4/5 Wavelengths: 1064nm (deep penetration), 980nm (improves circulation), 915nm (enhances oxygen delivery), 810nm (increases ATP production), 635nm (targets superficial receptors)
• INTENSE SUPERPULSE MODE (ISP): variable duty cycle pulsing to stimulate deeper tissues while reducing burn risk
• Powerful battery management: full power ~1 hour; low power up to ~4 hours; changeable battery; stationary 7-day option
• Smarter software operation: 10.1" HD touch screen Android platform, Wi‑Fi enabled software updates, fast parameter selection by condition/BMI/skin tone
• 5 Handpiece Optics: 30mm open zoom lens; 30mm curved contact lens; 10mm curved contact lens; 5mm TMJ lens; 30mm 360° rolling Large Massage Ball lens

Case studies / Reported outcomes
An injured racehorse reported ~80% tissue healing within 3 weeks of laser therapy; teams reported up to 40% reduced recovery time in some programs.

Specifications (extracted from table)
Frequencies: 0.2 to 20,000 Hz & ISP
Diode: High powered solid-state diode module
Weight: 4.2kg without battery, 4.8kg with battery (device dimensions 265(W)*270(L)*120(H) mm)
Battery: Full power ~1 hour; Low power up to ~4 hours; 7 day (stationary) option; changeable battery
Technology Platform: 10.1 Inch HD touch screen; Android platform; Wi‑Fi enabled software updates
Hand Piece Optics: 30mm open zoom lens; 30mm curved contact lens; 10mm curved contact lens; 5mm TMJ lens; 30mm 360° rolling Large Massage Ball lens
Customizable Protocols: Yes
Unlimited Patient History Data: Yes
Laser Cable: fibers of 400μm and 600μm with SMA905 connector
Pain Scale: Yes
BMI Tone Selection: Yes
Skin Tone Selection: Yes
Wavelength Combinations (nm): 1064nm + 980nm + 915nm + 810nm + 635nm
Wavelength Selectability: Any combinations + independent control
Intense Superpulse Peak (ISP): 55W + 2000mW (635nm)
Continuous Wave Power (CW): 40W + 2000mW (635nm)
Folding Screen: Yes
Shoulder Sling / Portable: Yes
Clinical Support: Yes

Caractéristiques / spécifications techniques

• Modèle: GBOX PLUS
• Technologie: Class 4 multi-wavelength diode laser
• Longueurs d'onde disponibles: 1064nm, 980nm, 915nm, 810nm, 635nm (combinaisons et contrôle indépendant)
• Modes: Continuous Wave (CW) et Intense Superpulse (ISP)
• Puissance CW: 40W + 2000mW (635nm)
• Puissance ISP (pic): 55W + 2000mW (635nm)
• Fréquences: 0.2 Hz – 20,000 Hz (+ ISP)
• Écran: 10.1" HD tactile, plate-forme Android, mises à jour Wi‑Fi
• Alimentation/batterie: batterie changeable, autonomie pleine puissance ~1h, basse puissance ~4h, option stationnaire 7 jours
• Poids & dimensions: ~4.2 kg sans batterie; ~4.8 kg avec batterie; 265 x 270 x 120 mm
• Accessoires main: 5 optiques de poignet/handpiece pour différents usages et profondeurs
• Connectique laser: fibres 400μm & 600μm avec connecteur SMA905
• Fonctionnalités logicielles: protocoles personnalisables, historique illimité des patients, sélection par BMI et teint de peau
• Utilisations cliniques: récupération post-course, blessures tendineuses, arthrite, gestion de la douleur, soins préventifs
