自动ESR分析仪 BK-ESR series

电动临床诊断随机取样

Application:
Applicable to hospital inspection departments, medical laboratories, research institutes, universities, disease control centers, etc.

Features:

• 7.0-inch color touch screen, real-time display of sample status.
• Randomly insert sample positions for testing at any time.
• Built-in thermal printer, can print dynamic ESR curve.
• Infrared optical detection and precise measurement, the test results automatically complete temperature compensation, pressure volume compensation, and ESR equation K value.
• With USB, Type-C interface and host computer supporting software, support uploading test results to LIS/HIS system.
• Power-off protection function, automatic saving of test results, and sample abnormality alarm and recording function.
• The base height is adjustable, with a leveling level to ensure accurate detection.

Caractéristiques / spécifications techniques:

• Model: BK-ESR20pro / BK-ESR40pro
• Application: Erythrocyte sedimentation rate analysis
• Measurement Method: Infrared detection
• Analysis Result: Westergren ESR value (mm/hour)
• Throughput: BK-ESR20pro – Maximum 40 tests/hour; BK-ESR40pro – Maximum 80 tests/hour
• Analysis Channels: 20 (load up to 20 samples for analysis at the same time) / 40 (load up to 40 samples for analysis at the same time)
• Loading Type: Load samples at any time, measure at any time
• Analysis Time: 30 minutes or 60 minutes selectable
• Sampling Interval: 3 min
• Measurement Range: 0~150 mm/h
• Temperature Compensation: The result is automatically corrected to the result at 18°C
• Result Resolution: 1 mm/1h and 1 mm/2h
• Blood Level Range: 46 mm ~ 64 mm
• HCT Range: 0.2 ~ 1.0
• Repeatability: 0~10 mm/h, SD ≤ 1.5 mm/h; >10 mm/h, CV ≤ 8%
• Channel Consistency: 0~10 mm/h, SD ≤ 1.5 mm/h; >10 mm/h, CV ≤ 8%
• Reading Accuracy: ±0.1 mm
• Display: 7-inch color LCD touch screen
• Communication Interface: Type-C, USB interface
• Printer: Built-in thermal printer
• Power Supply: AC110~220V, 50/60Hz
• External Size (W*D*H): 284*355*208 mm
• Net Weight: 5.6 kg (BK-ESR20pro) / 6.3 kg (BK-ESR40pro)
• Package Size (W*D*H): 339*544*249 mm
• Gross Weight: 8.7 kg (BK-ESR20pro) / 9.4 kg (BK-ESR40pro)
