教学显微镜 BFM-100

生物消色差LED式

简介
BIOBASE 的 BM-2CA / BM-2CBA 生物显微镜适用于常规实验室观察和教学用途，提供稳定的光学性能及灵活的观察方式。BM-2CA 为双目，BM-2CBA 为三目，适用于明场观察，配备消色差物镜和可调 LED 照明。

产品详情

• Brand: BIOBASE
• Product origin: CHINA
• Delivery time: Within 7 days
• Supply capacity: Factory Direct Supply
• Model: BM-2CA, BM-2CBA

技术参数（表）
Model | BM-2CA | BM-2CBA
View Head | Compensation free binocular head, Inclined at 30°, 360° rotatable, Interpupillary 55~75mm | Compensation free trinocular head, Inclined at 30°, 360° rotatable, Interpupillary 55~75mm
Eyepiece | P10X/18mm, P16X/11mm (both models)
Objective (Achromatic) | 4X N.A=0.10 WD=37.50mm; 10X N.A=0.25 WD=7.31mm; 40X N.A=0.65 WD=0.63mm; 100X (Oil) N.A=1.25 WD=0.18mm
Focusing | Coaxial Coarse & Fine Adjustable System, Range 15mm, Fine Division 0.002mm
Stage | BM-2CA: Mechanical Stage 130*130mm, Moving Range 70*30mm, Vernier 0.1mm; BM-2CBA: Mechanical Stage 130*125mm, Moving Range 70*30mm, Vernier 0.1mm
Condenser | Abbe NA1.25 condenser with Iris Diaphragm & Filter
Illumination | LED lamp, brightness adjustable
Filter | Yellow, green
Power Supply | AC85~240V, 50/60Hz
Package Size | BM-2CA: 435*330*235mm; BM-2CBA: 335*215*470mm
Gross Weight | 5.5kg

特性 / 技术规格

• 型号: BM-2CA（双目）、BM-2CBA（三目）
• 观察头: 倾角 30°，360° 可旋转，瞳距 55–75 mm
• 目镜: P10X/18mm 与 P16X/11mm
• 消色差物镜: 4X (N.A.0.10, WD 37.50 mm)、10X (N.A.0.25, WD 7.31 mm)、40X (N.A.0.65, WD 0.63 mm)、100X 油浸 (N.A.1.25, WD 0.18 mm)
• 对焦: 同轴粗微调，行程 15 mm，微分 0.002 mm
• 载物台: 机械载物台，移动范围 70×30 mm，游标 0.1 mm（不同型号尺寸略有差异）
• 聚光镜: Abbe N.A.1.25，带虹膜光阑与滤片
• 照明: 可调 LED 灯
• 滤片: 黄、绿
• 电源: AC 85–240 V, 50/60 Hz
• 包装尺寸及毛重按型号提供
